The ZAP Digital test ball is a robust voltage tester combined with a electricity meter tester. With its connectible load of 350 W / 1050 W power, digital and analogue electricity meters can be tested safely and quickly.

Thanks to its patented, waterproof load system and protective rubber housing, the ZAP test ball is indestructible and can be used under all conditions.

In addition, the voltage tester combines a phase tester, a phase sequence tester and a continuity tester.

• nominal voltage range: 50 – 500 V AC / 50 – 500 V DC

• display range: 24 – 500 V AC / 24 – 500 V DC

• continuity tester

• overvoltage category: CAT IV 500 V

• additional load from 350 W with overvoltage protection

• load indication through LCD-display

• precise display of the voltage 50 – 500 V AC / DC

• resistant to voltage – CAT IV 500 V – VDE-certified

• clear LED indicator for dangerous voltage

• 350 W / 1050 W additional load for fast startup test of electricity meters and detection of interference voltages

• full voltage indication without battery – maintenance free

• large LCD display with backlight

• quick continuity test

• continuity test with display up to 1000 kOhm

• phase tester with display “POL” and red LED

• rotating field tester with LED display left / right

• controller-monitored test with error detection to avoid false indications

• phase and phase sequence tests can also be performed with insulating gloves

• safety housing made of solid rubber is extremely shockproof

• test electrodes with thread for screwing on accessories

• easy handling

• additional load with thermal and overload protection

• extremely stable housing, even in cold environment

• IP 65 – waterproof
